DML 85L Horizontal & Veritcal Sun Louver | Steel & Aluminium Louvers DML Metal and Aluminium Sun Louvers
DML 85L Sun Louvers are reliable, easy to install, and high-quality design. DML 85L Louvers are made from either zinc aluminium (aluzinc) finishes or aluminium. The steel and aluminium louvre are coated with polyester caoted and the coloaur is based on this coating. With these enamel baked colour coating or powder coated colours, the finishes are guaranteed and will enhance the excellent appearance to all structural buildings.
DML 85L Sun Louvers apply lightweight clip on the carrier system to increase the efficiency of the system. The materials are made from aluminium and galvanized steel finishes that are ideal for interior and exterior designs. Sun louvers are coated with DML polyester which provides layer protection for the louvers from dust, rust, and scratches. DML 85L sun louvers are suitable for offices, universities colleges, toll plazas, airport terminals, and others, that provide an elegant and stylish design to your buildings.
Louvers
Aluminium, Galvanized Steel
• DML 85L/3V
• DML 85L/4V
• DML 85L/5V
• DML 85L/ 7V
• DML 85L/2H
Feature | Performance |
---|---|
Lightweight | The materials used are lighter than the average ceiling |
Durable | Tough and able to withstand pressure, intense heat, and tear |
Cost saving | Minimum maintenance required |
Sound insulation | Install noise-insulating multi-chamber frames to reduce noises |
Energy saving/efficient | Yes |
Environmental friendly | Materials used are reusable and recyclable which cause no harm to the environment |
Specification | Properties |
---|---|
Panel size effective width | 85mm |
Panel thickness | Galvanized steel: 0.4mm thick [gross wt: 3.6kg/m²] Aluminium: 0.55mm thick [gross wt: 2.85kg/m²] |
Panel end | Must not exceed 300mm from mullion |
Panel joint | Minimum of 100mm overlapped |
Carrier type and size | DML 85L/3V 48 W x 98 Dx 4880 L DML 85L/4V 38 W x 98 Dx 4880 L DML 85L/5V 33 W x 100 Dx 4880 L DML 85L/7V 40 W x 66 Dx 4880 L DML 85L/2H 38 W x 98 Dx 4880 L |
Aluminium carrier thickness | 1.0mm thick vertical fixed |
NA
NA
NA
Company | Installation | Minimum Order | Cover area |
---|---|---|---|
(Ceiling and Louvre Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
No Result found. |
No Photo & Brochure available
