DML Baffle Ceiling 190V | Aluminium Ceiling DML Strip Ceiling | Metal and Aluminium Strip and Open Ceiling
DML190V is a newly designed ceiling offer by DML. The design is the modification of traditional ceiling pattern combines with new elegant style to create an excellent illusion on the ceiling. DML 190V is made of aluminium. The open ceiling concept is applied to create rooms for plenum space that eases the additional installation services in the future. This aluminium ceiling applies to the V shape profile panel with the lightweight component system to enhance the performance of the system. Powder-coated finishes allow the ceiling to be protected from dust, rust, and scratches. The finishing also functions as an additional aesthetic purpose that will enlighten the design.
DML190V is a unique designed ceiling that fits in all kinds of structure and architectural buildings. This aluminium ceiling is applicable for both horizontal and vertical designs that are external as well as internal. DML 190V is relevant for baffle ceiling and ventilation louver. The design is able to make a great outlook for the structure and architectural buildings. This aluminium ceiling is suitable for offices, restaurants, commercial complexes, and others.
Metal Ceiling, Metal Cladding
Aluminium
• DML 190V
Feature | Performance |
---|---|
Durable | Tough and able to withstand pressure, heat, and tear |
Lightweight | Applies lightweight component |
Cost saving | Required minimum maintenance |
Environmental friendly | Materials are reusable and have no harm to environment |
Energy saving/efficient | Yes |
Specification | Properties |
---|---|
Panel maximum width and effective width | 2400mm x 185mm x 30mm |
Aluminium panel thickness | 1mm |
Standard panel spacing at center to center | 150mm |
Carrier type / Aluminium BC hollow section | 38mm (H) x 80mm (W) x 1mm (Thickness) x 6100mm (L) |
Maximum carrier spacing centre to centre fro height above 10m | Must not exceed 900mm |
Maximum carrier spacing at centre to centre | 1200mm |
NA
NA
NA
Company | Installation | Minimum Order | Cover area |
---|---|---|---|
(Ceiling and Louvre Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
