DML Strip Ceiling 85L Profille | Steel & Aluminium Ceiling DML Strip Ceiling | Metal and Aluminium Strip and Open Ceiling
DML strip ceiling 85L profiles are reliable, easy to install, and high-quality design. DML manufacture varieties of ceilings that are made from steel materials coated with polyester paint color either in aluzinc finishes or aluminum. Powder coating color is offered upon request. With these enamel baked color coating or powder coated colors, the finishes are guaranteed on the steel ceiling. The coatings allow rust-free, fungus free and long-lasting. Thus strip ceiling will enhance the excellent appearance to all structural buildings.
Strip ceiling is a modern way to panel ceiling. DML strip ceiling 85L profile, a linear pattern ceiling applied on C profile panel. DML strip ceiling is available for both louvers cladding and strip ceiling designs. The steel ceilings are designed uniquely and apply perfectly to the interior and exterior structure of buildings such as restaurant signage, office ceilings, and house cladding.
Metal Ceiling
Aluminium , Zinc Aluminium, Galvanized Steel
• DML85L
• DML85L/B
• DML85L/U
Feature | Performance |
---|---|
Lightweight | Lightweight clip-on carrier system |
Durable | Tough and able to withstand pressure, intense heat, tear and last for extended years |
Sound insulation | Noise-insulating multi-chamber frames are applied to reduce noises |
Energy saving/efficient | Yes |
Environmental friendly | Materials used are reusable and do not harm the environment. |
Specification | Properties |
---|---|
Panel size effective width | 85mm |
Thickness | Aluzinc panel: DML85L 0.4mm (gross wt: 4.1 kg/m²) DML85L/B 0.4mm (gross wt: 4.3 kg/m²) DML85L/U 0.4mm (gross wt: 4.6kg /m²) Aluminium panel : DML 85L 0.5mm (gross wt: 1.7 kg/m²) DML 85L/B 0.5mm (gross wt: 1.8 kg/m²) DML 85L/U 0.5mm (gross wt: 1.9kg/m²) |
Panel joint | Must be at minimum of 100mm overlapped |
Panel end holding from mullion | DML 85L: Must not exceed 300mm |
Carrier size | 35mm (W) x 35mm (D) x 4880mm (L) |
Galvanized steel carrier thickness | 0.7mm |
Type of suspension G.I. wire hanger | 14 gauge (by installer) |
Suspension thickness G.I bracing | 0.5mm |
Aluzinc L angle edge and corner finished thickness | 0.4mm |
NA
NA
NA
