DML Strip Ceiling U Profile | Steel & Aluminium Ceiling DML Strip Ceiling | Metal and Aluminium Strip and Open Ceiling
DML Strip Ceiling U Profiles are high-quality and reliable design. DML manufacture U profile ceilings that are made from aluminium and galvanized steel finishes. DML Strip Ceiling U Profile polyester coating colour is based on the colour chart. Plain finishes and perforated panel are used to acoustically treat the steel ceiling. The coating allows rust-free, fungus free and long-lasting. A single carrier is applied on this U profile steel ceiling to accommodate four different sizes of the panel width. Strip ceiling will enhance the excellent appearance to all structural buildings.
DML strip ceiling U profile is a linear pattern ceiling that applies on U shape profile panel. The steel ceilings are designed uniquely and apply perfectly to the interior and exterior structure of buildings such as restaurants, office ceilings, and commercial complexes.
Metal Ceiling
Aluminium, Galvanized Steel
• 30U
• 80U
• 130U
• 180U
Feature | Performance |
---|---|
Lightweight | Applied lightweight component system |
Durable | Able to withstand pressure, heat, and tear |
Cost saving | Required minimum maintenance |
Energy saving/efficient | Yes |
Environmental friendly | Materials used are reusable and recyclable which cause no harm to the environment |
Specification | Properties |
---|---|
Panel size effective width | 30U 30mm 80U 80mm 130U 130mm 180U 180mm |
Thickness | Aluminium panel: 0.5mm: 30U 80U 130U 180U Galvanized steel panel : 0.4mm: 30U 80U 130U 0.5mm: 180U |
Panel joint size | Minimum 100mm overlapped |
Panel end thickness | Must not exceed 300mm from mullion |
G.I carrier size | 30mm(W) x 35mm(D) x 4800mm(L)>br> |
Galvanized steel G.I carrier thickness | 0.7mm |
Galvanized steel suspension type | 14 gauge wire hanger |
Galvanized steel bracing suspension thickness | 0.5mm |
Galvanized end and corner finished thickness | 0.4mm[L angle] 0.5mm [U channel] |
NA
NA
NA
Company | Installation | Minimum Order | Cover area |
---|---|---|---|
(Ceiling and Louvre Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
