Electrical Conduit Pipe Smartube | Metal Conduit Pipe | Plain Conduit (Thread-less) Southern Steel Pipe Smartube
Electrical Conduit Pipe, threadless conduit, or plain conduit is a smooth cylindrical tube used to protect electrical wiring from penetration. It has no threads and is made from steel or other non-metallic materials.
This conduit is applied in simple electrical installations where there is no need to thread. These conduits are usually applied in residential, commercial, and industrial installations where wiring situations are very simple.
Tube / Pipe / Bar
Steel, Galvanized (Zinc-coated/Iron)
NA
Feature | Performance |
---|---|
Cost saving | Yes |
Impact Resistant | Yes |
Specification | Properties |
---|---|
Size | E 19, E 25, E 31, E 39, E 51 |
OD (mm) | 19.1, 25.4, 31.8, 38.1, 50.8 |
Nominal Wall Thickness (mm) | 1.2,1.4 |
Length (mm) | 3660 |
Weight (kg/pc) | 1.94, 2.62, 3.84, 4.64, 6.24 |
Primary Bundle (pc/bdl) | 10, 7, 5, 3 |
Master Bundle (pc/bdl) | 400, 250, 175, 125, 75 |
NA
NA
NA
Company | Installation | Minimum Order | Cover area |
---|---|---|---|
(Steel Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
No Result found. |
No Photo & Brochure available
