Galvanized Iron Conduit Pipe Smartube | Threaded Conduit Heavy Gauge Class B Southern Steel Pipe Smartube
Threaded Conduit Heavy Gauge Class B or BS31 Conduit Threaded-Heavy-Duty and threaded with standardized thread; sections securely connect to offer optimum protection for electrical installations.
This conduit finds application in environments that need added strength and durability, especially when the electrical systems are heavier. This conduit can be installed indoors as well as outdoors and finds application in most industrial uses where the need for wiring management in security is imperative.
Tube / Pipe / Bar
Steel, Galvanized (Zinc-coated/Iron)
NA
| Feature | Performance |
|---|---|
| Impact Resistant | Yes |
| Corrosion resistant | Yes |
| Specification | Properties |
|---|---|
| Trade Size Designator | 19, 25, 32, 38, 50 mm
3/4, 1, 1-1/4, 1-1/2, 2 In |
| Nominal Outside Diameter | 18.9, 25.2, 31.6, 37.9, 50.6 mm
0.745, 0.993, 1.245, 1.493, 1.992 In |
| Nominal Wall Thickness | 1.6, 1.8, 2.0mm
0.063, 0.071, 0.080 In |
| Unit Length | 3.05, 3.81 m |
| Nominal Weight | 2.14, 2.67, 2.90, 3.62, 3.66, 4.57, 5.00, 6.25, 7.44, 9.30 kg/pc
0.70, 0.95, 1.20, 1.64, 2.44 kg/m 0.21, 0.29, 0.37, 0.50, 0.74 kg/ft |
| Quantity | 10, 5, 3 Primary Bundle
50, 25, 15 Master Bundle |
NA
NA
NA
| Company | Installation | Minimum Order | Cover area |
|---|---|---|---|
| (Steel Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
| No Result found. | |||
No Photo & Brochure available
