Rigid Steel Pipe Smartube | Rigid Steel Conduit for Cable Management Southern Steel Pipe Smartube
The Rigid Steel Conduit MS IEC 61386-21: 2010 series & BS 4568 : PART 1 : 1970 Threaded Conduit Heavy Gauge incorporates the specification on rigid steel conduits used in cable management. These high-strength conduits or pipes are made of steel with the most excellent protection of electrical cables in different environments.
These conduits are normally used for those harsher environments that need tough protection of the electrical cables. This conduit may be employed in any industry, building, and infrastructure that will guarantee the cables are safely managed and protected against physical damage.
Tube / Pipe / Bar
Steel, Galvanized (Zinc-coated/Iron)
NA
| Feature | Performance |
|---|---|
| Cost saving | Yes |
| Time saving | Yes |
| Impact Resistant | Yes |
| Corrosion resistant | Yes |
| Specification | Properties |
|---|---|
| Trade Size Designator (mm) | 20, 25, 32 |
| Nominal Outside Diameter (mm) | 19.85, 24.80, 31.80 |
| Nominal Wall Thickness (mm) | 1.6 |
| Unit Length (m) | 3.00, 3.75, 3.81 |
| Nominal Weight | 2.14, 2.67, 2.72, 2.71, 3.39, 3.44, 3.56, 4.44, 4.51 kp/pc
0.713, 0.903, 1.185 kg/m 0.217, 0.275, 0.361 kg/ft |
| Quantity | 10, 5 Primary Bundle
50, 25 Master Bundle |
NA
NA
NA
| Company | Installation | Minimum Order | Cover area |
|---|---|---|---|
| (Steel Manufacturer) | No | 0 | Cyberjaya, Johor, Kedah, Kelantan, Kuala Lumpur, Labuan, Malacca, Negeri Sembilan, Pahang, Penang, Perak, Perlis, Putrajaya, Sabah, Sarawak, Selangor, Terengganu |
| No Result found. | |||
No Photo & Brochure available
